Audiopipe Professional Power Amplifier AQ-5000

Audiopipe professional power amplifier product number: AQ-5000

Specifications

• Out Power (8Ω): 2x600W • Out Power (4Ω): 2x1050W • Out Power (2Ω): 2x1400W • Out Power (BRIDGE) (8Ω): 1750W • Out Power (BRIDGE) (4Ω): 2300W • Frequency response @ Half Pwr: 15Hz-25KHz (+0/-1dB) • THD+Noise @ 1KHz Full Pwr: <0.03% • IMD 60Hz & 7KHz, 4:1:<0.038% • Signal to Noise Ratio: >102dB • Slew Rate (input filter limited): 40V/uS • Damping factor 1KHz @ 8Ohm: > 400:1 • Input sensitivity: Selectable (0.77V / 1.0V /1.44V) • Input Impendance: 10K Ohm Balance to ground • Input Connectors: Female XLR-3 & 6.35mm TRS Jack • Output Circuit Type: Class AB • Output Connectors: 4 Pole Speakon & Binding posts • Protections: Full short-circuit, Open-circuit, Thermal, Soft-start, DC viltage, Sub/Ultrasonic and RF • LED Indicators (per channel): Bridge, Parallel, Power, Singnal, Clip, Protect • Panel controls: Front-2 input attenuators Rear-Ground lift, mode selection, compressor • Cooling: Front-to-Back via 2 variable-speed fans • Power supply volatge: 110V AC/60Hz • Power supply Fuse (250): 12A • Dimensions: 19.0” x 17.3” x 5.2” • Weight: 55.1 lbs
